7486 The 7486 IC from 3M Electronic Solutions is a Quad 2-Input Exclusive OR Gate. It operates with a 5V supply voltage and interfaces directly with CMOS, NMOS, and TTL logic.
Mfr Part #:

7486

Available from 1 distributors
Mfr Name: 3M Electronic Solutions
3M Electronic Solutions
The 7486 IC from 3M Electronic Solutions is a Quad 2-Input Exclusive OR Gate. It operates with a 5V supply voltage and interfaces directly with CMOS, NMOS, and TTL logic.
✓ Total Stock: 231 pcs
$ Price Range: $0.99

7486 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
231 pcs
On Request
231 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

7486 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Gate Type
Industrial Grade
Interface
Medical Grade
Military Grade
Number of Gates
Storage Temperature
Tape & Reel
View Similar Products (0)

7486 Description

Short technical summary and product information.

The 7486 IC is a Quad 2-Input Exclusive OR (XOR) Gate IC, featuring four independent gates. Each gate performs the boolean operation Y = A ⊕ B using positive logic. This integrated circuit is designed for a wide operating voltage range, with a nominal supply voltage of 5V (4.75V to 5.25V).



Key electrical characteristics include a HIGH level input voltage of 2V and a LOW level input voltage of 0.8V. The output can source -0.4mA at a HIGH level and sink 16mA at a LOW level. Propagation delays are typically 22nS for LOW-to-HIGH and 15nS for HIGH-to-LOW transitions under specified test conditions.



The 7486 IC offers direct interface capabilities with CMOS, NMOS, and TTL logic families. It operates within a free air temperature range of 0°C to 70°C. The device is housed in a 14-pin package, with pin 14 designated for the positive supply and pin 7 for ground.



This component is equivalent to SN7486N and DM7486N. It is not recommended for new designs, and the 74LS Series - 74LS86 IC is suggested as an alternative.

7486 Quick Information

Product Type: Integrated Circuit
Series: 74
Canonical Name: 7486 Quad 2-Input Exclusive OR Gate IC
Subcategory: Exclusive OR (XOR) Gate

7486 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

7486 Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

7486 Features

  • Four independent 2-input XOR gates.
  • Operates with a 5V supply voltage.
  • Interfaces directly with CMOS, NMOS, and TTL.
  • Wide operating voltage range.
  • Low propagation delay times.

7486 Applications

  • Digital logic circuit design.
  • Signal processing applications.
  • Control system implementation.
  • Data manipulation tasks.

7486 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the 7486 IC?

The 7486 IC has a nominal supply voltage of 5V, with a recommended operating range of 4.75V to 5.25V.

What is the operating temperature range for the 7486 IC?

The 7486 IC operates in a free air temperature range of 0°C to 70°C.

What type of logic gates are in the 7486 IC?

The 7486 IC contains four independent 2-Input Exclusive OR (XOR) Gates.

What are the propagation delay times for the 7486 IC?

The propagation delay time is a maximum of 22nS for LOW-to-HIGH level output and a maximum of 15nS for HIGH-to-LOW level output.

Does the 7486 IC interface with TTL logic?

Yes, the outputs of the 7486 IC directly interface to CMOS, NMOS, and TTL logic.
