| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| China RoHS | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| ELV | |
| Flange Feature | |
| Halogen Free | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The 747090-2 is a D-Sub receptacle connector from TE Connectivity. It features 9 positions arranged in 2 rows, with female socket contacts. The connector is designed for through hole mounting with a press-fit termination, which provides a reliable solderless connection to the PCB. Contacts are gold plated for corrosion resistance and reliable signal transmission. The shell is made of steel with a tin plating, and the housing material has a UL94 V-0 flammability rating. The flange includes 4-40 threaded inserts for secure mating. This component is not EU RoHS compliant due to lead content and is affected by REACH with lead above the SVHC threshold. It is suitable for applications requiring a durable D-Sub interconnection with press-fit assembly.
9 positions.
Through hole.
Press-Fit.
Gold.
Steel, Tin Plated.
No, it is not RoHS compliant.
UL94 V-0.
