| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
39 pcs
|
39 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Failure Rate | |
| Features | |
| Flange Feature | |
| Housing Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| SVHC Present | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The TE Connectivity AMPLIMITE HDF-20 747052-3 is a 15-position D-Sub receptacle connector with female sockets. It features a free hanging (in-line) mounting style and IDC termination for ribbon cable, making it suitable for direct cable attachment without additional soldering. The connector uses a 2 (DA, A) shell size and layout, with a steel tin-plated shell and a housing/shell (4-40) flange feature. Contacts are made of phosphor bronze with a gold finish (30.0 µin thickness) for reliable signal transmission. The housing is black thermoplastic with a UL94 V-0 flammability rating. This connector is rated for 1.25 A current and operates over a temperature range of -55°C to 105°C. It includes a feed through feature for pass-through wiring applications.
D-Sub receptacle with female sockets.
15 positions arranged in 2 rows.
IDC for ribbon cable.
1.25 A.
-55°C to 105°C.
Gold, 30.0 µin (0.76 µm) thickness.
Free hanging (in-line).
