| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Amps) | |
| Features | |
| Lead Style | |
| Mounting Type | |
| Number of Pins | |
| Operating Temperature (Minimum/Maximum) | |
| Packaging Type | |
| Pcb Thickness (Minimum/Maximum) | |
| Screw Size | |
| Storage Temperature (Minimum/Maximum) | |
| Terminal Type | |
| Termination |
The Würth Elektronik 7461084 is a REDCUBE PRESS-FIT terminal from the WP-BUTR series, designed for high-current PCB applications. It features an internal M6 thread and eight pins arranged in two rows, with a press-fit termination for reliable solderless connection.
This terminal is rated for 160A continuous current and operates over a temperature range of -55°C to +150°C. The brass body with tin finish ensures good conductivity and corrosion resistance. The press-fit design requires a minimum insertion force of 40N per pin and provides a minimum extraction force of 30N per pin after 24 hours.
Mechanical specifications include a tightening torque of 3.9 N·m for the M6 screw, and compatibility with PCB thicknesses from 1.6mm to 3.2mm. The component is supplied in bulk packaging and has an MSL rating of 1 (unlimited floor life).
The rated current is 160 A.
The screw size is M6 and the tightening torque is 3.9 N·m.
It has 8 pins.
Mounting type is through hole, termination style is press-fit.
The operating temperature range is -55°C to +150°C.
PCB thickness from 1.6 mm to 3.2 mm is supported.
The material is brass with a tin surface finish.
