745-154 The WAGO 745-154 is a 4-contact PCB connector from the 745 Series. It features a 7.5mm pitch and a 32A current rating.
Mfr Part #:

745-154

Available from 1 distributors
Mfr Name: N-A
N-A
The WAGO 745-154 is a 4-contact PCB connector from the 745 Series. It features a 7.5mm pitch and a 32A current rating.
✓ Total Stock: 10 pcs
$ Price Range: $0.10

745-154 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ACK ELEKTRONIK ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

745-154 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Country of Origin
Current Rating
Depth
Failure Rate
Housing Material
Mounting Type
Number of Contacts
Number of Rows
Orientation
Pitch
Voltage Rating
Width
View Similar Products (0)

745-154 Description

Short technical summary and product information.

The WAGO 745-154 is a 4-contact PCB connector designed for through-hole mounting. Part of the 745 Series, this connector offers a 7.5mm pitch and a robust cage clamp wire connection method.



With a current rating of 32A and a voltage rating of 50V, it is suitable for various electrical applications. The housing is constructed from durable Polyamide 66 and comes in a grey color. It supports wire sizes from 0.08mm² to 4mm² (28 AWG to 12 AWG).



The connector has a 45° orientation and dimensions of 29mm width and 22.9mm depth. It is manufactured in Poland. This PCB connector is designed for reliable connections in electronic assemblies.

745-154 Quick Information

Product Type: PCB Connector
Series: 745
Canonical Name: WAGO 745 Series PCB Connector
Subcategory: PCB Connector

745-154 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

745-154 Estimated Pricing

Qty Low High
1+ $0.10 $0.10

Estimated market price range - modelled values for guidance only, not live distributor offers.

745-154 Features

  • 4-contact PCB connector with 7.5mm pitch.
  • Rated for 32A current and 50V voltage.
  • Through hole mount with cage clamp connection.
  • Durable Polyamide 66 housing material.
  • Supports wire sizes from 0.08mm² to 4mm².

745-154 Applications

  • Ideal for PCB power connections.
  • Suitable for industrial automation.
  • Used in power supply units.
  • General electronic assembly.

745-154 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the pitch of the WAGO 745-154 PCB connector?

The pitch of the WAGO 745-154 PCB connector is 7.5mm.

What is the current rating for the WAGO 745-154 connector?

The WAGO 745-154 connector has a current rating of 32A.

What is the voltage rating of the WAGO 745-154 PCB connector?

The WAGO 745-154 PCB connector is rated for 50V.

How many contacts does the WAGO 745-154 connector have?

The WAGO 745-154 connector has 4 contacts.

What type of wire connection does the WAGO 745-154 use?

The WAGO 745-154 uses a cage clamp wire connection method.

What is the mounting type for the WAGO 745-154 PCB connector?

The WAGO 745-154 PCB connector is a through-hole mount type.
