| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,978 pcs
|
3978 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
95 pcs
|
95 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Ambient Temperature (Rated Current) | |
| Automotive Grade | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| DC Resistance (Typical/Maximum) | |
| Frequency | |
| Halogen Free | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Operating Voltage | |
| Rated Current (Maximum @ IEC 62024-2-2020, Class C) | |
| Ratings | |
| Saturation Current (Typical @ |ΔL/L| < 30%) | |
| Shielding | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Termination Style | |
| Tolerance | |
| Type | |
| Width |
The Würth Elektronik 74477730 is a WE-PD series SMT shielded power inductor with a drum core wirewound construction. It offers an inductance of 1000 µH (1 mH) with ±20% tolerance. The rated current is 0.2 A based on a 40 K temperature rise, with a maximum DC resistance of 6 Ω. Two saturation current ratings are provided: 0.25 A typical at 10% inductance drop and 0.31 A typical at 30% drop. The self-resonant frequency is 2.2 MHz typical.
This inductor is shielded for reduced EMI and comes in a nonstandard 7345 package (7.3 mm x 7.3 mm x 4.5 mm). It is qualified to AEC-Q200 Grade 1 and operates over -40°C to +125°C. The component is RoHS compliant, REACH conform, and halogen-free. Performance rated current per IEC 62024-2-2020 is 0.37 A max.
Ideal for power supply filtering, DC/DC converter input/output, and automotive electronics where low current and high inductance are needed. The ferrite core material ensures stable performance across temperature.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.37 | $2.37 |
| 10+ | $2.11 | $2.11 |
| 50+ | $1.96 | $1.96 |
| 100+ | $1.89 | $1.89 |
| 500+ | $1.81 | $1.81 |
| 1,000+ | $1.66 | $1.66 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 1000 µH (1 mH) at 1 kHz/250 mV with ±20% tolerance.
The rated current based on a 40 K temperature rise is 0.2 A maximum. The performance rated current per IEC 62024-2-2020 is 0.37 A maximum.
The maximum DCR is 6 Ω, with a typical value of 3.27 Ω at 20°C.
The self-resonant frequency is 2.2 MHz typical.
It is supplied in a nonstandard 7345 package with dimensions 7.3 mm x 7.3 mm x 4.5 mm (height).
Yes, it is AEC-Q200 Grade 1 qualified.
It operates from -40°C to +125°C. The ambient temperature range for rated current is -40°C to +85°C.
