| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,577 pcs
|
1577 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,577 pcs
|
1577 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| AEC-Q200 | |
| Ambient Temperature (referring to IR) | |
| Automotive Grade | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Halogen Free | |
| Height | |
| Inductance | |
| Industrial Grade | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Freq | |
| Ratings | |
| Shielding | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
The Würth Elektronik 744762210A is a surface-mount wirewound ceramic inductor from the WE-KI series. It has an inductance of 100 nH with ±5% tolerance, a minimum Q factor of 60 at 350 MHz, and a maximum DC resistance of 180 mOhm. The rated current is 1 A at a temperature rise of 15 K, and the self-resonant frequency is at least 1.1 GHz.
This unshielded inductor is designed for general electronic equipment and is qualified to AEC-Q200 Grade 1, making it suitable for automotive applications. It operates over a temperature range of -40°C to +125°C, with a maximum ambient temperature of +110°C for rated current. The component is RoHS compliant, REACH unaffected, halogen-free, and has an MSL of 1.
The inductor is housed in a 1008 (2520 Metric) package with dimensions of approximately 2.5 mm x 2.0 mm x 1.6 mm. It is designed for surface-mount assembly and is suitable for high-frequency applications such as RF circuits, filtering, and impedance matching.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.47 | $0.47 |
| 10+ | $0.45 | $0.45 |
| 50+ | $0.42 | $0.42 |
| 100+ | $0.39 | $0.39 |
| 500+ | $0.36 | $0.36 |
| 1,000+ | $0.33 | $0.33 |
| 2,000+ | $0.30 | $0.30 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 100 nH with a tolerance of ±5%.
The rated current is 1 A, measured at a temperature rise of 15 K.
The maximum DC resistance is 180 mOhm at 20°C.
The minimum self-resonant frequency is 1.1 GHz.
It is available in a 1008 (2520 Metric) surface-mount package.
Yes, it is AEC-Q200 Grade 1 qualified.
The operating temperature range is -40°C to +125°C.
