74437529203101 is a shielded round-wire SMT high-current inductor from Würth Elektronik's WE-HCF family. It is designed for surface mount assembly in a 2920-style nonstandard package measuring 28.00 mm x 25.00 mm x 20.50 mm. The component uses a manganese-zinc ferrite core and is specified for an operating temperature range of -40°C to +125°C.
The inductor provides a nominal inductance of 100 µH with ±20% tolerance, measured at 100 kHz / 10 mA. Its rated current is 11.2 A maximum at a 50 K temperature rise, with a performance rated current of 10.5 A at 40 K following IEC 62024-2-2020. Typical saturation current is 7 A for a 10% inductance drop and 9.4 A for a 30% drop. DC resistance is 22.9 mΩ typical and 25.19 mΩ maximum at 20°C, and the self-resonant frequency is 4.3 MHz typical.
With a 250 V operating voltage rating, this inductor suits power conversion and filtering applications where high DC bias and stable inductance are required. Its shielded construction helps reduce electromagnetic interference, and the AEC-Q200 rating indicates suitability for automotive electronics.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.96 | $8.96 |
| 50+ | $7.87 | $7.87 |
| 100+ | $7.02 | $7.02 |
| 270+ | $6.51 | $6.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Inductance is 100µH ±20%, measured at 100 kHz and 10 mA.
Rated current is 11.2A maximum at ΔT=50K; performance rated current is 10.5A maximum at ΔT=40K.
DC resistance is 22.9mΩ typical and 25.19mΩ maximum at 20°C.
The self-resonant frequency is 4.3MHz typical.
It is a surface mount device in a nonstandard 2920 package measuring 28.00 x 25.00 x 20.50 mm.
It operates from -40°C to +125°C.
Yes, the inductor is shielded.
