| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
265 pcs
|
265 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating (Max) | |
| DC Resistance (DCR) (Max) | |
| Halogen Free | |
| Height (Max) | |
| Impedance @ Frequency | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Number of Lines | |
| Operating Temperature | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel | |
| Width |
The 742792901 is a WE-PF SMT EMI suppression power ferrite bead manufactured by Würth Elektronik eiSos. This component is designed for high-current EMI filtering applications, providing a typical impedance of 2900 ohms at 90 MHz. It supports a rated current of up to 10 A with a maximum DC resistance of only 9 milliohms, minimizing power loss.
The ferrite bead is rated for a maximum operating voltage of 120 V DC and operates over a temperature range of -40°C to +125°C. It is packaged in a 1280 SMD form factor with a recommended land pattern of 12.8 mm x 5.4 mm. The component is RoHS compliant, REACH conform, and halogen-free per JEDEC JS709B.
This part is suitable for use in general electronic equipment where EMI suppression is required. It should not be used beyond its rated current to avoid excessive heat generation. The moisture sensitivity level is MSL 1, allowing for flexible handling during assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.87 | $2.87 |
| 10+ | $2.81 | $2.81 |
| 50+ | $2.69 | $2.69 |
| 100+ | $2.58 | $2.58 |
| 250+ | $2.22 | $2.22 |
| 500+ | $2.06 | $2.06 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum impedance Zmax is 2900 ohms typical at 90 MHz.
The rated current IR is 10 A maximum at ΔT = 40 K.
The DC resistance RDC is 0.009 ohms maximum at 20°C.
The operating temperature range is -40°C to +125°C.
Yes, it is RoHS compliant per directive 2011/65/EU and 2015/863.
The maximum operating voltage V DC is 120 V.
The package size is 1280 SMD with dimensions 12 mm x 8 mm.
