| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
35 pcs
|
35 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Lead Spacing | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Wire Gauge or Range |
The Wago 734-350 is a 1-conductor male connector from the MCS MINI series, featuring 20 poles with 3.81mm pin spacing. This free hanging (in-line) plug is designed for quick and reliable wire connections in industrial control and automation systems.
It utilizes CAGE CLAMP push-in spring termination, allowing solid or stranded wires from 0.08 to 1.5mm² to be securely connected without tools. The connector is 100% protected against mismating, ensuring correct orientation during installation.
Electrical ratings include 300V and 10A, with an operating temperature range of -60°C to 100°C. Contact mating finish is tin, and the overall dimensions follow the formula L = (n-1)*3.81 + 5.9 + 0.45 mm, where n is the number of poles.
The orange color enhances visibility in crowded panels, and the free hanging design simplifies wiring in applications where board mounting is not required.
The connector has 20 positions.
The pin spacing is 3.81mm.
It is rated for 10A.
It is rated for 300V.
It is free hanging (in-line).
It accepts wires from 0.08 to 1.5mm².
It operates from -60°C to 100°C.
