| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
82 pcs
|
82 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Header Orientation | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Rated Current | |
| Storage Temperature | |
| Tape & Reel | |
| Termination Style | |
| Type | |
| Voltage |
The Wago 734-166/105-604 is a 6-position, 3.50mm pitch THR (Through-Hole Reflow) male header with a right angle orientation. It features 1.0 x 1.0 mm solder pins and is designed for through-hole mounting. The header is part of the MCS (Multi Connection System) family and utilizes CAGE CLAMP® spring pressure connection technology for reliable, vibration-resistant terminations.
Rated at 10A and 300V (UL/CSA Use Groups B and D) with a rated surge voltage of 2.5 kV, this header is suitable for demanding industrial environments. It accepts solid and fine-stranded conductors from 0.08 to 1.5 mm² (28-14 AWG). The operating temperature range is -60°C to 100°C.
The 100% protection against mismating ensures correct mating with compatible female plugs. The black housing and tin-plated contacts provide durability and corrosion resistance. This header is commonly used in PCB interconnect applications, including control panels, PLCs, and power distribution systems.
6 positions.
3.50 mm (0.138 inches).
10 A.
300 V (UL/CSA Use Group B and D) and up to 320 V (IEC/EN 60664-1 II/2).
Through Hole with solder pins.
-60°C to 100°C.
Tin.
