734-102/037-000 This Wago female plug terminal block features 2 positions with 3.5mm pitch and push-in spring (CAGE CLAMP) termination. Rated for 10A at 300V and operates from -60°C to 100°C.
Mfr Part #:

734-102/037-000

Available from 2 distributors
Mfr Name: Wago Corporation
Wago Corporation
This Wago female plug terminal block features 2 positions with 3.5mm pitch and push-in spring (CAGE CLAMP) termination. Rated for 10A at 300V and operates from -60°C to 100°C.
✓ Total Stock: 129 pcs

734-102/037-000 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Tomark Electronics Ltd ✓
Non-Authorised Inventory information
84 pcs
On Request
84 pcs On Request 1 On Request On Request On Request On Request On Request
Chanetech ✓
Non-Authorised Inventory information
45 pcs
On Request
45 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

734-102/037-000 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Current Rating
Features
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Operating Temperature Range
Pitch
Plug Wire Entry
Positions Per Level
Termination Style
Type
Voltage
Voltage Rating
Wire Gauge or Range
View Similar Products (0)

734-102/037-000 Description

Short technical summary and product information.

The Wago 734-102/037-000 is a 1-conductor female plug from the MCS MINI series, designed for use with matching male headers. It features a push-in spring (CAGE CLAMP) termination, accepting wire gauges from 0.08 to 1.5 mm² with a 180° wire entry. The 2-pole plug has a 3.5mm pitch and includes lateral locking levers and a strain relief plate for secure connections. Rated at 10A and 300V (IEC/UL), it operates over a wide temperature range of -60°C to 100°C. The housing is light gray with tin-plated contacts and is 100% protected against mismating, ensuring only same-pole-count headers can be mated. This plug is suitable for free-hanging (in-line) mounting and is RoHS3, REACH unaffected, and MSL 1 compliant (unverified).

734-102/037-000 Quick Information

Product Type: Terminal Block Plug, Female Sockets
Series: MCS MINI
Canonical Name: 1-Conductor Female Connector (Plug) with Push-In Spring Termination, 2-Pole, 3.5mm Pitch
Subcategory: Female Socket Plug

734-102/037-000 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

734-102/037-000 Features

  • Push-in spring termination (CAGE CLAMP).
  • 2-position, 3.5mm pitch female plug.
  • Rated for 10A at 300V.
  • Operates from -60°C to 100°C.
  • 100% protected against mismating.

734-102/037-000 Applications

  • Suitable for control cabinet wiring.
  • Ideal for industrial automation systems.
  • Used in PCB-to-wire connections.
  • Common in building automation applications.

734-102/037-000 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this terminal block plug have?

This plug has 2 positions (2-pole).

What is the pitch (pin spacing) of this plug?

The pitch is 3.5 mm (0.138 inches).

What is the current and voltage rating?

Rated at 10 A and 300 V (per IEC and UL).

What mounting type does this plug support?

Free hanging (in-line) mounting; it is a plug for use with a male header.

What wire gauge can this terminal block accept?

It accepts 0.08 to 1.5 mm² wire.

What color is the housing?

The housing is gray (light gray).

Does this plug have features to prevent mismating?

Yes, it includes 100% protection against mismating via retention latches (non-wire side).
