| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Material | |
| Contact Mating Finish | |
| Current | |
| Depth | |
| Height | |
| Housing Material | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Weight | |
| Width | |
| Wire Gauge or Range |
The Wago 733-203 is a 3-pole male plug connector with a 2.5mm pitch, designed for free hanging (in-line) mounting. It utilizes the CAGE CLAMP push-in spring termination system, enabling fast and reliable wire connections without screws. The connector accepts solid and fine-stranded conductors from 0.08 to 0.5 mm² (28-20 AWG) with a stripping length of 5-6 mm.
Electrically, the 733-203 is rated for 6 A (IEC/EN) or 4 A (UL) and offers multiple voltage ratings depending on the standard and use group: 150 V (UL Use Group B), 100 V (IEC III/3), 160 V (IEC III/2), and 320 V (IEC II/2). The rated impulse voltage is 2.5 kV (IEC III/3). The housing is made of gray Polyamide 66 (PA 66) with a V0 flammability rating per UL 94. Contacts are tin-plated electrolytic copper, and the clamp spring is chromium-nickel spring steel.
Mechanical dimensions include a width of 10 mm, height of 11.8 mm, and depth of 20.3 mm. The connector is 100% mismating-proof and codable, making it suitable for wire-to-wire connections in industrial control and automation applications.
The Wago 733-203 has 3 positions (3 poles) with 1 level.
The pitch is 2.5 mm (0.098 inches).
The IEC/EN rated current is 6 A; the UL rated current (Use Group B) is 4 A.
UL rated voltage (Use Group B) is 150 V. IEC/EN rated voltages: 100 V (III/3), 160 V (III/2), 320 V (II/2).
It is designed for free hanging (in-line) mounting.
It accepts solid and fine-stranded conductors from 0.08 to 0.5 mm² (28-20 AWG).
The operating temperature range is -60°C to +100°C.
