721-606 Wago 721-606 is a 6-position, single-level male plug with 5.00mm pitch, CAGE CLAMP push-in spring termination, rated 12A/320V IEC and 15A/300V UL.
Mfr Part #:

721-606

Available from 1 distributors
Mfr Name: Wago Corporation
Wago Corporation
Wago 721-606 is a 6-position, single-level male plug with 5.00mm pitch, CAGE CLAMP push-in spring termination, rated 12A/320V IEC and 15A/300V UL.
✓ Total Stock: 100 pcs
$ Price Range: $5.78 - $12.58

721-606 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

721-606 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Mating Finish
Current
Depth
Height
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Plug Wire Entry
Positions Per Level
Termination Style
Type
Voltage
Width
Wire Gauge or Range
View Similar Products (0)

721-606 Description

Short technical summary and product information.

The Wago 721-606 is a 1-conductor male connector from the MCS MIDI family, designed for 6-pole applications with a 5.00mm pin spacing. It features CAGE CLAMP push-in spring termination, accommodating solid, fine-stranded, and fine-stranded with insulated ferrule conductors from 0.08 mm² to 2.5 mm². The connector supports a strip length of 8-9 mm and is rated for 12 A at 320 V (IEC/EN 60664-1, Overvoltage III, Pollution 2/3) and 630 V at Overvoltage II. UL ratings provide 15 A at 300 V (Use Group B) and 10 A at 300 V (Use Group D), with UL 1977 rating 15 A at 600 V. The plug is free-hanging (in-line) with a 180° wire entry and tin-plated contact surfaces. Its compact dimensions are 33.2 mm wide, 14.3 mm high, and 27.5 mm deep, with a gray housing rated for an operating temperature range of -60°C to 100°C. This connector is 100% protected against mismating and must not be connected or disconnected under load.

721-606 Quick Information

Product Type: Male Connector
Series: 721
Canonical Name: 1-conductor male connector; CAGE CLAMP; 2.5 mm²; Pin spacing 5 mm; 6-pole
Subcategory: Plug

721-606 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

721-606 Estimated Pricing

Qty Low High
1+ $12.58 $12.58
10+ $8.94 $8.94
25+ $7.92 $7.92
50+ $7.30 $7.30
100+ $6.80 $6.80
250+ $6.30 $6.30
500+ $6.01 $6.01
1,000+ $5.78 $5.78

Estimated market price range - modelled values for guidance only, not live distributor offers.

721-606 Features

  • CAGE CLAMP push-in spring termination.
  • 6 positions with 5.00 mm pitch.
  • Rated 12 A at 320 V (IEC).
  • Accepts 0.08 to 2.5 mm² conductors.
  • Operating temperature -60°C to 100°C.

721-606 Applications

  • Ideal for industrial panel wiring harnesses.
  • Suitable for free-hanging in-line connections.
  • Use in control systems and automation equipment.
  • Works in environments with wide temperature range.
  • Tool-less installation with push-in spring clamp.

721-606 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the Wago 721-606 have?

The connector has 6 positions.

What is the pitch of the Wago 721-606?

The pitch is 5.00 mm.

What is the current rating of the Wago 721-606 under IEC standards?

The rated current is 12 A per IEC/EN 60664-1.

What is the voltage rating under UL 1059 Use Group B?

The rated voltage is 300 V and rated current is 15 A for UL 1059 Use Group B.

What is the mounting type of the Wago 721-606?

It is free hanging (in-line) with a 180° plug wire entry.

What wire sizes does the Wago 721-606 accept?

It accepts solid, fine-stranded, and fine-stranded with insulated ferrule conductors from 0.08 mm² to 2.5 mm².

What is the operating temperature range?

The operating temperature range is -60°C to 100°C.
