| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
88 pcs
|
88 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Features | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Wire Gauge or Range |
This product is a 1-conductor female connector from Wago's MCS MIDI series, part number 721-103/008-000. It features 3 positions with 5.00mm pitch and uses CAGE CLAMP® spring-pressure termination, eliminating the need for screw tightening or ferrule crimping.
Electrical ratings: According to IEC/EN 60664-1, it is rated for 16A and 320V (overvoltage category III, pollution degree 3), with a rated impulse withstand voltage of 4kV. Under UL 1059, it is rated 15A (Use group B) and 10A (Use group D) at 300V. The UL 1977 rating is 15A/600V.
The connector accepts wire cross sections from 0.08 to 2.5mm² with a strip length of 8-9mm. It is designed for free-hanging (in-line) mounting with snap-in mounting feet. Dimensions: 16.5mm width, 18.8mm height, 26.45mm depth. The housing is light gray and contact surfaces are tin-plated.
This connector is 100% protected against mismating and features board lock and retention latches. It is suitable for use in industrial control, building automation, and power distribution applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.90 | $6.90 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 3 positions.
The pin spacing is 5.00 mm.
16 A
320 V
Free Hanging (Snap-in mounting feet)
CAGE CLAMP® spring-pressure termination (actuated by operating tool).
0.08 to 2.5 mm²
