The Amphenol ICC 71918-114 is a 14-position, 2-row rectangular connector header designed for board-to-cable/wire applications. It features a 2.54mm pitch and a shrouded 4-wall design with latch lock/eject hooks for secure mating. The header uses through hole mounting and solder termination for reliable connections.
This connector is constructed with a gray, glass-filled thermoplastic insulator rated UL94 V-0 for flammability. The contacts are made of phosphor bronze with a square shape and feature a Gold, GXT™ finish with a thickness of 30.0µin. The insulation height is 17.40mm and the contact length is 2.90mm.
Key design features include a keying slot and mounting flange for proper alignment and secure attachment to the PCB. The header has a row spacing of 2.54mm and all 14 positions are loaded.
The pitch is 2.54mm (0.100").
It has 14 positions in 2 rows, all loaded.
It is a through hole mount connector with solder termination.
The contact finish is Gold, GXT™ with a thickness of 30.0µin (0.76µm).
The insulation is glass-filled thermoplastic with a UL94 V-0 flammability rating.
