| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Resistance (Maximum @ after 50,000 cycles) | |
| Contact Resistance (Maximum) | |
| Contact Underplating | |
| Current Rating | |
| Dielectric Voltage | |
| Durability | |
| ESD Rating (HBM) | |
| Halogen Free | |
| Insulation Resistance | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Material | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Normal Force | |
| Number of Contacts | |
| Number of Rows | |
| Operating Temperature Range | |
| Pitch | |
| Shock | |
| Storage Condition | |
| Storage Temperature | |
| Termination Finish | |
| Vibration | |
| Voltage Rating |
The Bourns 70ADJ-4-ML1 is a spring loaded male connector from the 70AD series, designed for reliable board-to-board connections in compact electronic assemblies. It features 4 contacts arranged in a single row with a 4mm pitch, enabling space-efficient designs. The connector uses a compression contact interface with gold plated contacts (30µin Au over nickel underplating) for low contact resistance and high corrosion resistance.
Electrical ratings include 3A per contact current capacity and 30VDC voltage rating, with a maximum contact resistance of 25mΩ initially and 50mΩ after 50,000 cycles. The insulator is glass reinforced thermoplastic with UL 94V-0 flammability rating, and the termination finish is tin alloy. The connector is rated for operating temperatures from -55°C to 125°C and meets MSL 1 moisture sensitivity level.
Mechanical durability is rated at 50,000 cycles minimum, with a minimum normal force of 100 grams at 0.51mm working height. The connector withstands vibration of 10-55 Hz at 0.06 inches D.A. and shock of 50 G for 11 ms. It is RoHS compliant, lead free, and halogen free, with an ESD rating (HBM) of 3B. The surface mount package is suitable for automated assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.12 | $2.12 |
| 10+ | $1.80 | $1.80 |
| 30+ | $1.66 | $1.66 |
| 60+ | $1.58 | $1.58 |
| 120+ | $1.51 | $1.51 |
| 270+ | $1.43 | $1.43 |
| 510+ | $1.36 | $1.36 |
| 1,020+ | $1.30 | $1.30 |
| 2,520+ | $1.22 | $1.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 4 contacts in a single row.
The pitch is 4.00mm (0.157 inches).
The current rating is 3A per contact.
The voltage rating is 30 VDC.
The connector is surface mount (SMD).
The connector is rated for 50,000 cycles minimum.
The operating temperature range is -55°C to 125°C.
