| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,260 pcs
|
2260 pcs | On Request | 1 | On Request | On Request | 1727+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Conflict Minerals | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Halogen Free | |
| Industrial Grade | |
| Material | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Contacts | |
| Number of Rows | |
| Pitch | |
| SVHC Present | |
| Tape & Reel |
The Bourns 70AAJ-5-F1 is a spring-loaded female connector featuring 5 compression contacts arranged in a single row with a 2.54mm (0.100") pitch. The contacts are made of copper alloy with a 30.0µin (0.76µm) gold finish, ensuring reliable electrical performance and corrosion resistance.
This connector is designed for surface mount technology (SMT) assembly, making it suitable for automated pick-and-place processes. The compression contact design provides a low-profile, board-to-board interconnection solution without the need for soldering on the mating side.
Typical applications include test and measurement equipment, programming jigs, and any design requiring a separable, low-insertion-force connection. The gold-plated contacts offer excellent durability and signal integrity for repeated mating cycles.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.18 | $2.18 |
| 10+ | $1.65 | $1.65 |
| 24+ | $1.53 | $1.53 |
| 120+ | $1.48 | $1.48 |
| 264+ | $1.28 | $1.28 |
| 504+ | $1.24 | $1.24 |
| 1,008+ | $1.16 | $1.16 |
| 2,520+ | $1.10 | $1.10 |
| 5,016+ | $1.08 | $1.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 5 contacts arranged in a single row.
Surface mount (SMD).
Gold with a thickness of 30.0µin (0.76µm).
Copper alloy.
