7.3728mhz This 7.3728MHz crystal quartz resonator from NDK America, Inc. is housed in an SMD7050 package. It offers a frequency stability of +/-10ppm and an aging rate of 3ppm/year.
Mfr Part #:

7.3728mhz

Available from 2 distributors
Mfr Name: NDK America, Inc.
NDK America, Inc.
This 7.3728MHz crystal quartz resonator from NDK America, Inc. is housed in an SMD7050 package. It offers a frequency stability of +/-10ppm and an aging rate of 3ppm/year.
✓ Total Stock: 1,948 pcs
$ Price Range: $0.50

7.3728mhz Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
OTL Components ✓
Non-Authorised Inventory information
1,080 pcs
On Request
1080 pcs On Request 1 On Request On Request On Request On Request On Request
Spartce Electronics. ✓
Non-Authorised Inventory information
868 pcs
On Request
868 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

7.3728mhz Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Frequency Stability
Mounting Type
SVHC Present
View Similar Products (0)

7.3728mhz Description

Short technical summary and product information.

The NDK America, Inc. 7.3728mhz is a crystal quartz resonator designed for surface mount applications. It features a compact SMD7050 package, making it suitable for space-constrained designs.



Key electrical specifications include an aging rate of 3ppm/year and a drive level of 0.1mW. The frequency stability is rated at +/-10ppm, ensuring reliable performance in various operating conditions. The loading capacitance is specified at 20pF.



This component is ideal for applications requiring precise frequency control. Its surface mount design facilitates automated assembly processes. The product is manufactured by NDK America, Inc., a known supplier of frequency components.

7.3728mhz Quick Information

Product Type: Crystal Quartz Resonator
Canonical Name: 7.3728MHz Crystal Quartz Resonator
Subcategory: Quartz Crystal

7.3728mhz Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

7.3728mhz Estimated Pricing

Qty Low High
1+ $0.50 $0.50

Estimated market price range - modelled values for guidance only, not live distributor offers.

7.3728mhz Features

  • SMD7050 package for surface mounting.
  • Frequency stability of +/-10ppm.
  • Aging rate of 3ppm/year.
  • Typical drive level of 0.1mW.
  • Loading capacitance of 20pF.

7.3728mhz Applications

  • Suitable for frequency generation circuits.
  • Ideal for compact electronic devices.
  • Used in various communication systems.
  • Applicable in instrumentation designs.

7.3728mhz FAQs

5 frequently asked questions generated from this part’s specifications.
What is the frequency stability of the 7.3728mhz crystal resonator?

+/-10ppm

What is the aging rate for this crystal resonator?

3ppm/year

What is the typical drive level for the 7.3728mhz crystal resonator?

0.1mW

What is the loading capacitance specified for this crystal resonator?

20pF

What is the package type for the 7.3728mhz crystal resonator?

SMD7050
