| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22,500 pcs
|
22500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
457 pcs
|
457 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
37 pcs
|
37 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Style | |
| Termination | |
| Voltage Rating |
The 7-338069-6 is a 6-position surface mount receptacle from TE Connectivity, part of the Micro-Match product family. It features 2 rows of fork-shaped contacts on a 2.54mm pitch with a 2.54mm row spacing, suitable for board-to-board or cable-to-board interconnection.
Designed with a friction lock for secure mating retention and a red insulation housing with UL94 V-0 flammability rating. The tin-plated contacts provide reliable conductivity for general-purpose applications. The operating temperature range is -40°C to 105°C and the voltage rating is 100VDC.
The receptacle is surface mount solder terminated and includes a pick-and-place feature for automated assembly. It is compliant with EU RoHS, REACH (no SVHC), and has a moisture sensitivity level of 1 (unlimited floor life).
| Qty | Low | High |
|---|---|---|
| 1+ | $1.44 | $1.44 |
| 10+ | $1.23 | $1.23 |
| 100+ | $1.04 | $1.04 |
| 900+ | $0.89 | $0.89 |
| 1,800+ | $0.85 | $0.85 |
| 2,700+ | $0.83 | $0.83 |
| 4,500+ | $0.80 | $0.80 |
| 6,300+ | $0.78 | $0.78 |
| 9,000+ | $0.76 | $0.76 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions arranged in 2 rows.
2.54mm (0.100").
Surface mount (SMD).
100VDC.
-40°C to 105°C.
Yes, compliant with EU RoHS Directive 2011/65/EU including Delegated Directive 2015/863/EU.
UL94 V-0.
