| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
845 pcs
|
845 pcs | On Request | 1 | On Request | On Request | On Request | On Request | 2026-02-16 21:33:16 |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Resistance (Maximum) | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Maximum) | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Housing Material | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
TE Connectivity's ELCON Micro 7-2204801-8 is a vertical through-hole header designed for wire-to-board power applications. It features 16 male pin positions arranged in 2 rows with a 3.00mm pitch, providing a compact high-density interconnect solution. The header is shrouded with a 4-wall design and includes a locking ramp for secure mating with compatible cable terminals. Key electrical ratings include a maximum current of 12.5A per contact and a voltage rating of 600V AC or DC, with a low contact resistance of 5mΩ max. The operating temperature range spans -40°C to 105°C. Constructed with a copper alloy contact material with tin plating (100µin) and a thermoplastic housing rated UL94-V0, the device is halogen-free and suitable for harsh environments. The board guide feature simplifies alignment during assembly. Common applications include servers, switches, power supplies, industrial control, and test equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.80 | $3.80 |
| 10+ | $3.23 | $3.23 |
| 25+ | $3.02 | $3.02 |
| 50+ | $2.88 | $2.88 |
| 100+ | $2.74 | $2.74 |
| 300+ | $2.54 | $2.54 |
| 500+ | $2.45 | $2.45 |
| 1,000+ | $2.33 | $2.33 |
| 2,500+ | $2.19 | $2.19 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
16 power positions, all loaded.
3.00mm (0.118 inches).
12.5A maximum per contact.
600V maximum AC or DC.
Through hole with solder termination.
-40°C to 105°C.
Yes, it is halogen-free as per the datasheet.
