7-2178711-6 6 position, 2.54mm pitch surface mount receptacle with tin contact finish. Features push-pull fastening and pick and place capabilities.
Mfr Part #:

7-2178711-6

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
6 position, 2.54mm pitch surface mount receptacle with tin contact finish. Features push-pull fastening and pick and place capabilities.
✓ Total Stock: 900 pcs
$ Price Range: $0.55

7-2178711-6 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
900 pcs
900 pcs On Request 1 On Request On Request On Request On Request On Request

7-2178711-6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Type
Fastening Type
Features
Insulation Color
Insulation Height
Lead Spacing
Lead Style
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Style
Tape & Reel
Termination
Voltage Rating

7-2178711-6 Description

Short technical summary and product information.

The TE Connectivity 7-2178711-6 is a 6-position, 2-row rectangular receptacle connector with a 2.54mm pitch and 2.54mm row spacing. It features a push-pull fastening mechanism and is designed for surface mount soldering, making it suitable for automated assembly. The connector has tin-plated forked contacts with a contact finish thickness of 118.1 µin (3.00 µm).



This receptacle is rated for 100 VDC and operates over a temperature range of -30°C to 85°C. It includes a pick and place feature for efficient surface mount placement. The insulation is black, with an insulation height of 5.30 mm. The connector is classified as RoHS3 compliant and REACH unaffected, with an MSL of 1 (unlimited).



Typical applications include board-to-board or cable interconnections where a compact, low-profile connector is required. The surface mount design and pick and place compatibility make it ideal for high-volume production environments.

7-2178711-6 Quick Information

Product Type: Receptacle
Canonical Name: 6 Position 2.54mm Pitch SMD Receptacle, Tin Contact Finish
Subcategory: Female Sockets

7-2178711-6 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Non-Compliant

7-2178711-6 Estimated Pricing

Qty Low High
3,600+ $0.55 $0.55

Estimated market price range - modelled values for guidance only, not live distributor offers.

7-2178711-6 Features

  • 6 position, 2.54mm pitch receptacle
  • Surface mount solder termination
  • Tin plated forked contacts
  • Push-pull fastening mechanism
  • Pick and place compatible

7-2178711-6 Applications

  • Suitable for board-to-board connections
  • Used in cable-to-board interconnects
  • Ideal for automated SMT assembly
  • Common in industrial control systems

7-2178711-6 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

6 positions, all loaded.

What is the pitch of this connector?

2.54 mm (0.100 inches)

What is the voltage rating?

100 VDC

What is the mounting type?

Surface mount (SMD) with solder termination.

What is the operating temperature range?

-30°C to 85°C

What is the contact finish?

Tin, with a thickness of 118.1 µin (3.00 µm).

What fastening type does this connector use?

Push-pull fastening.
