6NQ222MEFDD Ceramic capacitor, 2200 pF, 500V, ±20% tolerance, X5F dielectric, radial disc, through hole mounting.
Mfr Part #:

6NQ222MEFDD

Available from 1 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
Ceramic capacitor, 2200 pF, 500V, ±20% tolerance, X5F dielectric, radial disc, through hole mounting.
✓ Total Stock: 6,000 pcs

6NQ222MEFDD Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
6,000 pcs
On Request
6000 pcs On Request 1 On Request On Request 2026-02-25 06:16:38 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

6NQ222MEFDD Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Capacitance
Diameter
Height
Lead Spacing
Lead Style
Mounting Type
Operating Temperature
Package / Case
Temperature Coefficient
Tolerance
Voltage
View Similar Products (0)

6NQ222MEFDD Description

Short technical summary and product information.

The 6NQ222MEFDD from Kyocera AVX is a ceramic capacitor with a capacitance of 2200 pF and a rated DC voltage of 500V. It features an X5F temperature coefficient with ±20% tolerance, operating reliably over -55°C to 125°C.



This radial disc capacitor uses through-hole mounting with straight leads spaced 6.00mm apart. The component measures 9.00mm in diameter and 3.00mm in seated height, making it suitable for general purpose applications requiring high voltage handling in a compact form.



Designed for general purpose use, the 6NQ222MEFDD can be employed in decoupling, filtering, and bypass circuits where a 500V rating provides headroom for high-voltage DC lines. The X5F dielectric offers moderate temperature stability, with capacitance change within ±15% over the operating range.

6NQ222MEFDD Quick Information

Product Type: Ceramic Capacitor
Canonical Name: 6NQ222MEFDD - Ceramic Capacitor, 2200 pF, 500V, X5F, Radial Disc
Subcategory: Radial Disc Ceramic Capacitor

6NQ222MEFDD Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

6NQ222MEFDD Features

  • 2200 pF capacitance value.
  • Rated for 500V DC operation.
  • X5F temperature coefficient.
  • ±20% capacitance tolerance.
  • Radial disc through-hole package.

6NQ222MEFDD Applications

  • General purpose decoupling and bypass circuits.
  • High-voltage DC filtering up to 500V.
  • Power supply smoothing applications.

6NQ222MEFDD FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance of the 6NQ222MEFDD?

2200 pF.

What is the voltage rating?

500V DC.

What is the tolerance?

±20%.

What is the temperature coefficient?

X5F.

What is the operating temperature range?

-55°C to 125°C.

What is the package type?

Radial, Disc.

What is the mounting type?

Through Hole.
