| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
45 pcs
|
45 pcs | On Request | 1 | 8 | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Depth | |
| Height | |
| Industrial Grade | |
| Isolation | |
| Medical Grade | |
| Military Grade | |
| Storage Temperature | |
| Tape & Reel | |
| Weight | |
| Width |
This Siemens 6ES7131-4BF00-0AA0 is an electronic module designed for the ET 200S system, providing 8 digital inputs with a rated voltage of 24V DC. The module has a narrow profile, measuring only 15mm in width, which is beneficial for space-constrained control cabinets.
Key electrical specifications include an input voltage range for signal '0' from -30 to +5V and for signal '1' from +15 to +30V. The typical input current for signal '1' is 5mA. Input delay is specified with minimum and maximum values of 2ms and 4.5ms respectively for both rising and falling edges. The module supports shielded cable lengths up to 1000m and unshielded up to 600m.
Potential separation is provided between the input channels and the backplane bus, with isolation tested at 500V DC. The module also features reverse polarity protection and a status indicator LED for digital inputs. It is designed for direct plug-in installation into ET 200S terminal modules, simplifying integration into Siemens automation systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The module has 8 digital inputs.
The rated input voltage is 24V DC.
The typical input current for signal '1' is 5 mA.
The maximum shielded cable length is 1000 meters.
The module measures 15mm in width, 81mm in height, and 52mm in depth.
Yes, there is potential separation between the channels and the backplane bus.
