| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Frequency | |
| Height | |
| Input Connector | |
| Input Type | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Storage Temperature | |
| Voltage | |
| Width |
The ENG ELECTRIC CO., LTD 6A-601DB15-029 is a 60W AC-DC desktop power supply designed for ITE applications. It provides a regulated 15V output at 4A, featuring low ripple noise and a 100% burn-in test.
The adapter accepts a universal AC input voltage range of 90-264VAC at 47-63Hz, making it suitable for international use. It utilizes an IEC 320-C14 input connector and a standard barrel plug output (2.5mm I.D. x 5.5mm O.D. x 9.5mm) with positive center polarization. The unit is designed for natural convection cooling and operates within a temperature range of 0°C to 40°C.
Compliance with various safety and EMC standards is met, including UL 62368-1, IEC62368-1, FCC CFR 47 PART 15B, and EN55032. The device also meets energy efficiency requirements such as CEC, DoE Level VI, and ErP Stage 2. Its dimensions are 121.0mm x 52.0mm x 33.0mm.
The 6A-601DB15-029 has an output voltage of 15V and an output current of 4A.
The power rating for the 6A-601DB15-029 is 60W.
The input voltage range is 90-264 VAC.
It uses an IEC 320-C14 input connector.
The operating temperature range is 0°C to 40°C.
Yes, it meets DoE Level VI efficiency standards.
