691709710304 4 position, 5mm pitch, surface mount wire to board terminal block from Würth Elektronik. Rated for 6A and 300V with screw termination.
Mfr Part #:

691709710304

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
4 position, 5mm pitch, surface mount wire to board terminal block from Würth Elektronik. Rated for 6A and 300V with screw termination.
✓ Total Stock: 380 pcs
$ Price Range: $3.68 - $5.26

691709710304 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Chanetech ✓
Non-Authorised Inventory information
380 pcs
On Request
380 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

691709710304 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Resistance
Current
Features
Housing Material
Insulator Material
Lead Spacing
Mating Orientation
Mounting Type
Number of Levels
Operating Temperature Range
Pitch
Positions Per Level
Screw Size
Tape & Reel
Torque
Voltage
Wire Gauge
Wire Termination
View Similar Products (0)

691709710304 Description

Short technical summary and product information.

The Würth Elektronik 691709710304 is a 4-position wire to board terminal block from the WR-TBL series. It features a 5.00mm pitch and is designed for surface mount assembly with a horizontal mating orientation. The terminal block uses a screw - leaf spring, wire guard termination method and accepts 14-30 AWG wire. Electrical ratings include 6A current and 300V voltage, with a maximum contact resistance of 20 mOhm. The insulator is made of high temperature PA46, and the housing is brass with tin-plated solder tails. The operating temperature range is -40 to 130°C. It is RoHS compliant and has a UL94 V-0 flammability rating. Packaging is tape and reel with cap. This component is suitable for general electronics equipment and is designed for reflow soldering processes.

691709710304 Quick Information

Product Type: Wire to Board Terminal Block
Series: 7097
Canonical Name: 4 Position 5mm Pitch Side Entry Wire to Board Terminal Block, Surface Mount
Subcategory: Wire to Board

691709710304 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

691709710304 Estimated Pricing

Qty Low High
1+ $5.26 $5.26
10+ $4.84 $4.84
50+ $4.45 $4.45
100+ $4.09 $4.09
200+ $3.68 $3.68

Estimated market price range - modelled values for guidance only, not live distributor offers.

691709710304 Features

  • 4 positions with 5.00mm pitch.
  • Rated for 6A and 300V.
  • Surface mount with horizontal entry.
  • Screw termination with wire guard.
  • RoHS compliant and UL94 V-0 rated.

691709710304 Applications

  • Ideal for wire to board connections in industrial controls.
  • Used in power supply and lighting applications.
  • Suitable for general electronics requiring reliable screw termination.

691709710304 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 691709710304 have?

4 positions.

What is the pitch of this terminal block?

5.00 mm (0.197 inches).

What is the current rating?

6 A.

What is the voltage rating?

300 V.

What is the mounting type?

Surface mount.

What wire sizes does it accept?

14-30 AWG solid or stranded wire.

What is the operating temperature range?

-40 to 130 °C.
