691701320010B Würth Elektronik WR-TBL Series 7013B PCB header, 10 positions, 3.81mm pitch, vertical orientation, through hole mounting, shrouded (4 side).
Mfr Part #:

691701320010B

Available from 2 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
Würth Elektronik WR-TBL Series 7013B PCB header, 10 positions, 3.81mm pitch, vertical orientation, through hole mounting, shrouded (4 side).
✓ Total Stock: 558 pcs
$ Price Range: $5.52

691701320010B Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
500 pcs
On Request
500 pcs On Request 6 On Request On Request On Request On Request On Request
Chanetech ✓
Non-Authorised Inventory information
58 pcs
On Request
58 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

691701320010B Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Automotive Grade
Color
Contact Mating Finish
Contact Resistance
Current
Features
Header Orientation
Industrial Grade
Insulator Flammability Rating
Insulator Material
Lead Spacing
Lead Style
Medical Grade
Military Grade
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Positions Per Level
Termination Style
Type
Voltage
View Similar Products (0)

691701320010B Description

Short technical summary and product information.

The Würth Elektronik 691701320010B is a 10-position, single-level PCB header from the WR-TBL Series 7013B. It features a 3.81mm pitch and a vertical, shrouded (4 side) design with through hole solder termination. The insulator is black LCP rated UL94 V-0, and the pins are brass with tin over nickel plating.



Electrically, the header is rated for 10A (cULus) / 8A (VDE) with a working voltage of 300V (cULus) / 250V (VDE). Withstanding voltage is 1600V (cULus) / 1400V (VDE), and maximum contact resistance is 20 mΩ. The operating temperature range is -40°C to +130°C per datasheet.



This header is designed for industrial applications requiring reliable wire-to-board connections. The shrouded design provides polarization and protection for the mating connector. The vertical orientation allows for straight board-to-wire routing.

691701320010B Quick Information

Product Type: Terminal Block Header
Series: 7013B
Canonical Name: WR-TBL Series 7013B PCB Header, 3.81mm Pitch, 10 Positions, Vertical, Through Hole, Shrouded (4 Side)
Subcategory: Shrouded Header

691701320010B Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 (Unlimited)
REACH Status: Non-Compliant

691701320010B Estimated Pricing

Qty Low High
250+ $5.52 $5.52

Estimated market price range - modelled values for guidance only, not live distributor offers.

691701320010B Features

  • 10 positions in a single level.
  • 3.81mm pitch vertical shrouded header.
  • Rated 10A (cULus) and 8A (VDE).
  • Through hole solder termination.
  • Black LCP insulator rated UL94 V-0.

691701320010B Applications

  • Industrial control and automation systems.
  • Power supply and distribution boards.
  • Building automation and HVAC equipment.
  • PLC and I/O module connections.

691701320010B FAQs

5 frequently asked questions generated from this part’s specifications.
How many positions does the 691701320010B have?

It has 10 positions in a single level.

What is the pitch of this header?

The pitch is 3.81mm (0.150 inches).

What is the current rating?

Rated current is 10A (cULus) and 8A (VDE).

What is the voltage rating?

Working voltage is 300V (cULus) and 250V (VDE).

What mounting type does this header use?

Through hole mounting with solder termination.
