| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Material | |
| Contact Resistance | |
| Current | |
| Insulator Material | |
| Lead Spacing | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik 691416600002 is a screwless spring clamp terminal block from the WR-TBL Series 4166. It is designed for wire-to-board connections with a vertical cable entry and through-hole mounting on a PCB. This 2-position terminal block features a 10.16 mm pitch, providing a compact yet robust solution for power distribution and signal connections.
Electrically, it is rated for 10 A (UL) / 16 A (VDE) at working voltages of 300 VAC (UL) and 750 VAC (VDE). Withstanding voltages are 1.6 kV (UL) and 3 kV (VDE), with a maximum contact resistance of 20 mΩ. The terminal block accepts wire sizes from 16 to 30 AWG (solid or stranded) with a strip length of 7 mm.
The insulator is made of PA6/66 with a flammability rating of UL94 V-0, and contacts are INOX steel with a copper alloy wire guard. The product is RoHS compliant and lead-free. Soldering is per JEDEC lead-free wave soldering standards. Packaging is in boxes.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.58 | $2.58 |
| 10+ | $2.34 | $2.34 |
| 50+ | $2.20 | $2.20 |
| 100+ | $2.01 | $2.01 |
| 400+ | $1.63 | $1.63 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 10.16 mm.
It has 2 positions.
10 A (UL) and 16 A (VDE).
300 VAC (UL) and 750 VAC (VDE).
Through Hole.
16 to 30 AWG (solid or stranded).
-30°C to +120°C.
