| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Resistance | |
| Current | |
| Housing Material | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik WR-TBL Series 4156 691415620003 is a through-hole terminal block with a screwless push-in termination mechanism. It features a 10.16 mm pitch and a 45° (135°) wire entry angle relative to the PCB, allowing space-efficient connections. With 3 positions per level and 1 level, it accommodates solid wires from 22 to 16 AWG and stranded wires from 22 to 18 AWG.
Electrically, the terminal block is rated for 15 A current (cULus), 13.5 A (VDE), and 10 A (UL). Working voltage is 300 V AC (cULus) and 1000 V AC (VDE), with withstanding voltages of 1600 V AC and 4200 V AC respectively. Contact resistance is 20 mΩ max.
Constructed with a PA66 insulator (UL94 V-0, gray), INOX steel housing, copper alloy wire guard, and stainless steel spring. Pin material is copper alloy with tin over nickel plating. The soldering process is JEDEC lead-free wave soldering.
The terminal block is RoHS compliant and operates in a temperature range of -30°C to +120°C. It is packaged in a box. This part is active with an expected lifetime greater than 10 years.
10.16 mm (0.400 in).
3 positions per level, with 1 level.
15 A (cULus), 13.5 A (VDE), and 10 A (UL).
Working voltage 300 V AC (cULus) and 1000 V AC (VDE). Withstanding voltage 1600 V AC (cULus) and 4200 V AC (VDE).
Through hole mounting.
Solid wire 22 to 16 AWG; stranded wire 22 to 18 AWG.
-30°C to +120°C.
