| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,131 pcs
|
1131 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Resistance | |
| Current | |
| Insulator Material | |
| Lead Style | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Tape & Reel | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik 691411510006 is a 6-position, single-level wire-to-board terminal block from the WR-TBL series 4115. It features a 5.08 mm pitch and a horizontal cable entry orientation, making it suitable for space-constrained PCB layouts. The screwless push-button clamp termination allows for quick and tool-free wire connection, accommodating solid or stranded wires from 30-16 AWG (0.05-1.31 mm²) with a 10 mm strip length.
This terminal block is rated for 10 A current and 300 VAC working voltage (UL) or 250 VAC (VDE), with a withstanding voltage of 1.6 kV (UL) and 2 kV (VDE). The contact resistance is a maximum of 20 mΩ. The insulator is made of PA6/66 with a UL94 V-0 flammability rating, and the metal housing is constructed from inox steel, ensuring robust mechanical performance.
The component is designed for through-hole mounting and is compatible with JEDEC lead-free wave soldering processes. It operates over a temperature range of -30°C to +120°C. The gray housing color and compact design make it a practical choice for a variety of wire-to-board interconnection applications in general electronic equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.67 | $2.67 |
| 10+ | $2.39 | $2.39 |
| 50+ | $2.21 | $2.21 |
| 100+ | $1.97 | $1.97 |
| 252+ | $1.51 | $1.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This terminal block has 6 positions per level.
The pitch is 5.08 mm.
The current rating is 10 A for both UL and VDE standards.
The working voltage is 300 VAC (UL) and 250 VAC (VDE).
This terminal block is designed for through-hole mounting.
It supports solid and stranded wires from 30-16 AWG (0.05-1.31 mm²).
The operating temperature range is -30°C to +120°C.
