691359740008

The Würth Elektronik 691359740008 is a WR-TBL Series 3597 8-position terminal block plug with a 5.08mm pitch. It features an IDC termination style for quick and reliable wire connection without stripping. The plug has a 90° wire entry angle and is designed for free hanging (in-line) mounting. The insulator is made of green PA66 with UL94 V-0 flammability rating, and the contacts are copper alloy with tin plating. The plug includes a mating flange and retention latches on the non-wire side for secure locking. Electrical ratings include 7A current (cULus), 300VAC working voltage, 1.6kV withstanding voltage, and 20mOhm maximum contact resistance. It accepts solid or stranded wire from 22 to 18 AWG (0.326-0.823 mm²). Operating temperature range is -40°C to 115°C. The component is RoHS compliant and lead-free. Packaging is in boxes. This plug is suitable for use in general electronics equipment requiring reliable pluggable connections. For applications demanding higher safety, such as aerospace or medical, written approval from Würth Elektronik is required.
