| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Resistance | |
| Current | |
| Features | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| Screw Size | |
| Termination Style | |
| Torque | |
| Type | |
| Voltage | |
| Wire Gauge or Range | |
| Withstanding Voltage |
The Würth Elektronik 691344710007 is a 7-position, single-level terminal block plug with female sockets, designed for a 5.00mm pitch. It features screw termination with a leaf spring and wire guard for reliable wire clamping, accommodating solid or stranded wire from 24-12 AWG (0.205-3.31 mm²). The plug is free hanging (in-line) with a 90° wire entry, making it suitable for space-constrained applications.
Rated for 300VAC working voltage and 15A (cULus) / 17A (VDE) current, it offers a dielectric withstanding voltage of 1.6kV and a maximum contact resistance of 20 mOhm. The operating temperature range is -40°C to 105°C.
Constructed with a PA66 insulator (UL94 V-0 flammability rated), brass metal housing, and steel zinc-plated terminal screws (M3.0, torque 0.50 Nm), the plug includes retention latches on the non-wire side for secure mating. It is RoHS compliant and lead-free. Packaging is in a box.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.30 | $7.30 |
| 10+ | $6.67 | $6.67 |
| 50+ | $6.29 | $6.29 |
| 100+ | $5.79 | $5.79 |
| 400+ | $4.78 | $4.78 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
7 positions.
5.00mm.
15A (cULus) and 17A (VDE).
300VAC.
Free hanging (in-line).
24-12 AWG (0.205-3.31 mm²).
-40°C to 105°C.
