691318400007 This is a 7.62mm pitch, 7-position shrouded terminal block header from Würth Elektronik. It features through hole vertical mounting, tin plated contacts, and a green PBT insulator rated UL94 V-0.
Mfr Part #:

691318400007

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
This is a 7.62mm pitch, 7-position shrouded terminal block header from Würth Elektronik. It features through hole vertical mounting, tin plated contacts, and a green PBT insulator rated UL94 V-0.
✓ Total Stock: 7 pcs
$ Price Range: $3.83

691318400007 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
7 pcs
On Request
7 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

691318400007 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Material
Contact Mating Finish
Contact Resistance
Current
Current Rating
Features
Halogen Free
Header Orientation
Insulator Material
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Operating Temperature
Pitch
Positions Per Level
SVHC Present
Termination Style
Type
Voltage
Voltage Rating
Withstanding Voltage
View Similar Products (0)

691318400007 Description

Short technical summary and product information.

The Würth Elektronik 691318400007 is a 7-position, single-level terminal block header from the WR-TBL series. It has a 7.62mm pitch and a shrouded design with mating flanges for secure connections. The header is rated for 300V and 20A, with a contact resistance of 20 mOhm maximum.



Constructed with a green PBT insulator (UL94 V-0 flammability rating) and brass contacts with tin solder tail plating, this component is suitable for wave soldering processes only. It operates over a temperature range of -40°C to 105°C.



This vertical through-hole header is designed for PCB mounting and is commonly used in industrial control, power distribution, and automation equipment where reliable, high-current interconnections are required.

691318400007 Quick Information

Product Type: Terminal Block Header
Series: 3184
Canonical Name: Würth Elektronik WR-TBL 691318400007 7.62mm Pitch 7-Position Through Hole Vertical Terminal Block Header
Subcategory: Shrouded Header

691318400007 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Non-Compliant
Lead Free: Yes

691318400007 Estimated Pricing

Qty Low High
150+ $3.83 $3.83

Estimated market price range - modelled values for guidance only, not live distributor offers.

691318400007 Features

  • 7.62mm pitch for high-density wiring.
  • Rated for 300V and 20A operation.
  • Through hole vertical mounting design.
  • Green PBT insulator with UL94 V-0 rating.
  • Mating flange for secure connection.

691318400007 Applications

  • Used in industrial control systems.
  • Suitable for power distribution panels.
  • Ideal for automation equipment wiring.
  • Common in HVAC and building automation.

691318400007 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of this terminal block header?

The pitch is 7.62mm.

How many positions does the header have?

It has 7 positions.

What is the current rating?

The current rating is 20A.

What is the voltage rating?

The voltage rating is 300V.

What is the mounting type?

Through hole, vertical orientation.

What is the operating temperature range?

-40°C to 105°C.

Is this header RoHS compliant?

Yes, it is RoHS3 compliant and lead free.
