| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
120 pcs
|
120 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Material | |
| Contact Mating Finish | |
| Contact Resistance | |
| Current | |
| Current Rating | |
| Header Orientation | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Termination Style | |
| Type | |
| Voltage | |
| Working Voltage |
The 691313510003 is a 3-position right angle PCB header from the WR-TBL series 313 by Würth Elektronik. It features a 5.08mm pitch and through-hole mounting for secure board attachment. The header has a shrouded design with male pins, meeting the requirements of wire-to-board connections.
Electrical specifications include a current rating of 20 A, working voltage of 300 VAC, and a maximum contact resistance of 20 mOhm. It withstands 1.6 kV (cULus) and 2.5 kV (VDE) respectively. The insulator is made of PBT with UL94 V-0 flammability rating. Contact pins are brass with tin plating.
The component supports an operating temperature range of -40°C to 105°C and is solderable via wave process only. It comes in a box package and is RoHS compliant and lead free. Safety certifications include cULus (E315414) and VDE (40023195).
| Qty | Low | High |
|---|---|---|
| 1+ | $0.56 | $0.56 |
| 10+ | $0.50 | $0.50 |
| 50+ | $0.50 | $0.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
3 positions.
5.08 mm.
20 A.
300 VAC.
Through hole.
-40°C to 105°C.
Yes, RoHS compliant.
