691247610006 Würth Elektronik WR-TBL Series 2476 terminal block with 2 positions, 3 levels, 10.16mm pitch, and 20A rated current. Side entry with rising cage clamp for secure wire termination.
Mfr Part #:

691247610006

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
Würth Elektronik WR-TBL Series 2476 terminal block with 2 positions, 3 levels, 10.16mm pitch, and 20A rated current. Side entry with rising cage clamp for secure wire termination.
✓ Total Stock: 10 pcs
$ Price Range: $7.71 - $11.32

691247610006 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

691247610006 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Current
Features
Lead Spacing
Lead Style
Mating Orientation
Mounting Type
Number of Levels
Pitch
Positions Per Level
Voltage
Wire Gauge
Wire Termination
View Similar Products (0)

691247610006 Description

Short technical summary and product information.

The Würth Elektronik 691247610006 is a WR-TBL Series 2476 terminal block designed for wire-to-board connections. It features 2 positions per level across 3 levels, providing a total of 6 connection points. The pitch is 10.16mm, offering ample spacing for high-voltage or high-current applications. This terminal block is rated for 20A continuous current, making it suitable for power distribution and industrial control circuits.



The component uses a side entry design with a rising cage clamp mechanism, ensuring reliable and vibration-resistant wire retention. The PCB mounting interface includes a recommended hole pattern with a pin-to-pin spacing of 10.16mm. The overall length of the block is 15.24mm, and the dimensions are designed for straightforward integration into standard PCB layouts.



Typical applications include power supplies, industrial automation, and building management systems where secure and maintainable wire connections are required. The WR-TBL series is known for its robust construction and compliance with industry standards for terminal blocks.

691247610006 Quick Information

Product Type: Terminal Block
Series: 2476
Canonical Name: Würth Elektronik WR-TBL Series 2476 2-Position 3-Level 10.16mm Pitch Terminal Block
Subcategory: Wire to Board

691247610006 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Compliant
Lead Free: Yes

691247610006 Estimated Pricing

Qty Low High
1+ $11.32 $11.32
10+ $9.91 $9.91
50+ $8.96 $8.96
100+ $8.02 $8.02
500+ $7.71 $7.71

Estimated market price range - modelled values for guidance only, not live distributor offers.

691247610006 Features

  • 2 positions per level, 3 levels total.
  • 10.16mm pitch for high voltage spacing.
  • Rated for 20A continuous current.
  • Side entry with rising cage clamp.
  • WR-TBL Series 2476 from Würth Elektronik.

691247610006 Applications

  • Power supply output terminal connections.
  • Industrial control panel wiring.
  • Building automation system interfaces.
  • HVAC equipment power distribution.

691247610006 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the pitch of this terminal block?

The pitch is 10.16mm.

How many positions does this terminal block have?

It has 2 positions per level, with 3 levels, for a total of 6 pins.

What is the current rating of this terminal block?

The rated current is 20A.

What type of termination does this terminal block use?

It uses a rising cage clamp termination.

What is the manufacturer and series of this part?

It is manufactured by Würth Elektronik and belongs to the WR-TBL Series 2476.
