| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Color | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Current | |
| Industrial Grade | |
| Insulator Color | |
| Insulator Flammability Rating | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Mating Orientation | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Screw Size | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik WR-TBL Series 2416 terminal block offers 10 positions in a single level with a 10.16 mm pitch. It uses a through hole mounting configuration with horizontal wire entry, allowing convenient board-edge wiring. The wire termination method is a screw-driven rising cage clamp that accommodates 14 to 30 AWG wire. The green PA6/66 insulator carries a UL94 V-0 flammability rating. Electrical ratings include 14 A current (cULus and VDE), working voltage of 300 V AC (cULus) and 750 V AC (VDE), with contact resistance of 20 mΩ. The operating temperature range spans from -30 °C to +120 °C. The component is packaged in a box and conforms to RoHS requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.49 | $6.49 |
| 10+ | $5.68 | $5.68 |
| 50+ | $5.13 | $5.13 |
| 100+ | $4.60 | $4.60 |
| 500+ | $4.42 | $4.42 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10.16 mm
14 A (cULus and VDE)
300 V AC (cULus) and 750 V AC (VDE)
Through Hole
10 positions, 1 level
14 to 30 AWG
