691241610009 WR-TBL Series 2416 terminal block with 9 positions, 10.16mm pitch, horizontal entry, and rising cage clamp termination. Rated for 14A and 300V (cULus) / 750V (VDE).
Mfr Part #:

691241610009

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
WR-TBL Series 2416 terminal block with 9 positions, 10.16mm pitch, horizontal entry, and rising cage clamp termination. Rated for 14A and 300V (cULus) / 750V (VDE).
✓ Total Stock: 10 pcs
$ Price Range: $4.05 - $4.63

691241610009 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

691241610009 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Contact Material
Contact Plating
Contact Resistance
Current
Current Rating
Insulator Flammability Rating
Insulator Material
Lead Spacing
Lead Style
Mating Orientation
Medical Grade
Military Grade
Mounting Type
Number of Levels
Operating Temperature
Pitch
Positions Per Level
Screw Size
Tape & Reel
Voltage
Wire Gauge
Wire Termination
View Similar Products (0)

691241610009 Description

Short technical summary and product information.

The Würth Elektronik 691241610009 is a 9-position wire-to-board terminal block from the WR-TBL Series 2416. It features a 10.16mm pitch and horizontal entry with a rising cage clamp termination, making it suitable for PCB mounting. The insulator is made of green PA6/66 with UL94 V-0 flammability rating, and contacts are copper alloy with nickel plating. The terminal screw is steel with zinc plating, and the wire guard is copper alloy with tin over nickel. Electrical ratings include 14A current (cULus/VDE), working voltage of 300V AC (cULus) and 750V AC (VDE), withstanding voltage of 1600V (cULus) and 3000V (VDE), and contact resistance of 20 mΩ. The terminal block accepts 14-30 AWG wire, requires a strip length of 6mm, and a tightening torque of 0.5 Nm. Operating temperature range is -30°C to +120°C. It comes in a box packaging. This component is RoHS3 compliant and lead-free. cULus and VDE approvals are documented. The through-hole mounting and horizontal orientation facilitate straightforward PCB integration in industrial and commercial applications.

691241610009 Quick Information

Product Type: Wire to Board Terminal Block
Series: 2416
Canonical Name: WR-TBL Series 2416, 9 Position, 10.16mm Pitch, Horizontal Entry, Rising Cage Clamp, Wire to Board Terminal Block
Subcategory: Wire to Board

691241610009 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Non-Compliant
Lead Free: Lead free

691241610009 Estimated Pricing

Qty Low High
1+ $4.63 $4.63
10+ $4.05 $4.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

691241610009 Features

  • 9 positions with 10.16mm pitch for dense wiring.
  • Rated for 14A current and 300/750V AC voltage.
  • Rising cage clamp termination for secure connections.
  • Accepts 14-30 AWG wire with 6mm strip length.
  • RoHS3 compliant and lead-free.

691241610009 Applications

  • Used in industrial control panels for power distribution.
  • Suitable for PCB mounting in automation equipment.
  • Ideal for wire-to-board connections in commercial appliances.
  • Common in building automation and HVAC systems.

691241610009 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the 691241610009 terminal block have?

It has 9 positions.

What is the pitch of this terminal block?

The pitch is 10.16mm.

What is the current rating of the 691241610009?

It is rated for 14A under both cULus and VDE conditions.

What is the voltage rating of this terminal block?

Working voltage is 300V AC (cULus) and 750V AC (VDE).

What is the mounting type for the 691241610009?

It is through hole, mating orientation horizontal with board.

What wire gauge does this terminal block accept?

It accepts 14-30 AWG wire.

What is the termination type of the 691241610009?

Screw - Rising Cage Clamp.
