Mfr Part #:

691241610008

Würth Elektronik 691241610008 is a 8-position wire-to-board terminal block with 10.16mm pitch and rising cage clamp termination. It is rated for 14A and 300V, with through-hole mounting and a green insulator.

✓ Total Stock: 20 pcs

$ Price Range: $2.83 - $4.15

691241610008 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Bristol Electronics ✓ Non-Authorised Inventory information	20 pcs On Request	20 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

691241610008 Description

Short technical summary and product information.

The Würth Elektronik 691241610008 is a wire-to-board terminal block from the WR-TBL Series 2416. It features 8 positions with a 10.16mm pitch and a rising cage clamp termination for secure wire connections. The block is rated for 14A current (cULus and VDE) and 300V (cULus) / 750V (VDE) working voltage, making it suitable for industrial and power distribution applications.

The insulator is made of PA6/66 with UL94 V-0 flammability rating, colored green. Contacts are copper alloy with nickel plating, and terminal screws are steel with zinc plating. The wire guard is copper alloy with tin over nickel. Operating temperature range is -30°C to +120°C.

The terminal block is through-hole mounted and mates horizontally with the board. It can accommodate wire gauges from 14 to 30 AWG, with a wire strip length of 6 mm and tightening torque of 0.5 Nm. Contact resistance is 20 mΩ.

Packaging is in boxes. The part is RoHS3 compliant and REACH unaffected. It has cULus (E150931) and VDE (40021365) approvals. This product is ideal for PCB applications requiring reliable, high-current connections in a compact form factor.

691241610008 Quick Information

Product Type: Wire to Board Terminal Block

Series: 2416

Canonical Name: Terminal Block, Wire to Board, 8 Positions, 10.16mm Pitch, Rising Cage Clamp, Through Hole, Horizontal

Subcategory: Wire to Board

691241610008 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: Non-Compliant

Lead Free: Yes

691241610008 Estimated Pricing

Qty	Low	High
1+	$4.15	$4.15
10+	$3.64	$3.64
50+	$3.29	$3.29
100+	$2.95	$2.95
500+	$2.83	$2.83

Estimated market price range - modelled values for guidance only, not live distributor offers.

691241610008 Features

8 positions with 10.16mm pitch.
Rising cage clamp for secure wire termination.
Rated 14A current and 300V/750V working voltage.
Through-hole mounting with horizontal wire entry.
UL94 V-0 rated PA6/66 insulator material.

691241610008 Applications

Ideal for power distribution in industrial control panels.
Used in PCB applications requiring high current capacity.
Suitable for factory automation and machinery wiring.
Common in building automation and HVAC systems.

691241610008 FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does this terminal block have?

It has 8 positions.

What is the pitch of the terminal block?

The pitch is 10.16 mm.

What is the current rating?

The current rating is 14 A (cULus and VDE).

What is the voltage rating?

Working voltage is 300 V AC (cULus) and 750 V AC (VDE).

What is the mounting type?

Through hole, horizontal with board.

What wire gauge can it accommodate?

Wire gauge range is 14 to 30 AWG.

What is the operating temperature range?

-30°C to +120°C.

Category	Wire to Board
Manufacturer Name	Würth Elektronik
Color	Green
Contact Material	Copper Alloy
Contact Plating	Nickel
Contact Resistance	20 mΩ
Current	14 A
Current Rating	14 A
Insulator Flammability Rating	UL94 V-0
Insulator Material	PA6/66
Lead Spacing	10.16 mm
Length	76.2 mm
Mating Orientation	Horizontal with Board
Mounting Type	Through Hole
Number of Levels	1
Number of Positions	8
Operating Temperature	-30°C to +120°C
Pitch	10.16mm
Positions Per Level	8
Screw Size	M3
Voltage	300 V
Voltage Rating	300 V
Wire Gauge	14-30 AWG
Wire Termination	Screw - Rising Cage Clamp
