| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Current | |
| Current (Rated) | |
| Features | |
| Flammability Rating | |
| Industrial Grade | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| SVHC Present | |
| Screw Material | |
| Screw Plating | |
| Screw Size | |
| Tape & Reel | |
| Termination Style | |
| Tightening Torque | |
| Voltage | |
| Wire Gauge | |
| Wire Guard Material | |
| Wire Section | |
| Wire Strip Length | |
| Wire Termination | |
| Withstanding Voltage (Minimum @ 1 min) | |
| Working Voltage |
The Würth Elektronik WR-TBL Series 2346 691234610004 is a 4 position, single level, through hole wire to board terminal block with a 10.16mm pitch. It features a screw rising cage clamp wire termination and is designed for horizontal mating orientation with the PCB.
This terminal block is rated for 20A continuous current and 300V working voltage (UL) or 750V (VDE). It accepts wire sizes from 12 to 30 AWG (solid or stranded) with a strip length of 6mm. The insulator is made of green PA6/66 with a UL94 V-0 flammability rating.
Electrical performance includes a contact resistance of 20 mΩ and withstanding voltage of 1600V (UL) / 3000V (VDE) for 1 minute. The contacts are copper alloy with nickel plating, and the M3 steel screws have a zinc plating. The tightening torque is 0.5 Nm.
Mechanical features include front and side interlocking for multi-position assembly and mid wire entry level. The operating temperature range is -30°C to +120°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.21 | $7.21 |
| 10+ | $6.31 | $6.31 |
| 50+ | $5.71 | $5.71 |
| 100+ | $5.10 | $5.10 |
| 500+ | $4.80 | $4.80 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions in a single level.
The pitch is 10.16mm (0.400 inches).
The rated current is 20 A.
The working voltage is 300 V (UL) and 750 V (VDE).
It is a through hole mounting terminal block.
It accepts 12 to 30 AWG wire.
The operating temperature range is -30°C to +120°C.
