| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Color | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Current | |
| Current Rating | |
| Features | |
| Flammability Rating | |
| Housing Color | |
| Industrial Grade | |
| Insulator Material | |
| Lead Spacing | |
| Mating Orientation | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature Range | |
| Pitch | |
| Positions Per Level | |
| SVHC Present | |
| Screw Material | |
| Screw Plating | |
| Screw Size | |
| Tape & Reel | |
| Termination Style | |
| Tightening Torque | |
| Voltage | |
| Wire Gauge | |
| Wire Guard Material | |
| Wire Strip Length | |
| Wire Termination | |
| Withstanding Voltage (Minimum @ UL) | |
| Withstanding Voltage (Minimum @ VDE) | |
| Working Voltage (Nominal @ UL) | |
| Working Voltage (Nominal @ VDE) |
The 691233610004 is a 4-position wire to board terminal block from Würth Elektronik's WR-TBL 2336 series. It features a 10.16mm pitch and uses a screw rising cage clamp termination for reliable wire connection. The through hole mounting allows for secure PCB attachment.
This terminal block is rated for 20A continuous current and has working voltage ratings of 300V (UL) and 750V (VDE). It accepts wire from 12 to 30 AWG with a strip length of 6mm. The insulator is made of PA6/66 with a UL94 V-0 flammability rating, ensuring safety in demanding environments.
Design features include a side interlocking mechanism for stacking multiple blocks, and the contacts are copper alloy with nickel tin plating. The operating temperature range is -30°C to +120°C, making it suitable for industrial applications. The block is RoHS3 compliant and lead-free.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.11 | $7.11 |
| 10+ | $6.22 | $6.22 |
| 50+ | $5.62 | $5.62 |
| 100+ | $5.04 | $5.04 |
| 500+ | $4.74 | $4.74 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions (2 positions per level, 2 levels).
10.16mm (0.400 inches).
20 A (UL and VDE rated).
300 V UL and 750 V VDE.
Through Hole.
12-30 AWG.
-30°C to +120°C.
