| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
15 pcs
|
15 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Resistance | |
| Current | |
| Features | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Screw Size | |
| Tape & Reel | |
| Torque | |
| Voltage | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik 691216810101 is a single-position terminal block from the WR-TBL Series 2168, designed for wire-to-board applications. It features a 10.00mm pitch and a horizontal mating orientation with the board. The terminal block uses a rising cage clamp wire termination mechanism, secured by an M3 screw with a torque rating of 0.5 Nm (4 Lb·In). It accepts solid or stranded wire from 12 AWG to 30 AWG (0.05-3.31 mm²) with a strip length of 6 mm.
Electrical ratings are provided under both UL and VDE standards: UL current rating of 14 A and voltage rating of 300 VAC, with a withstanding voltage of 1.6 kV. VDE ratings are higher at 24 A and 750 VAC, with a withstanding voltage of 3 kV. Contact resistance is specified at 20 mΩ maximum. The insulator is made of PA6/66 with a flammability rating of UL94V0, and the terminal screw is steel with zinc plating. The wire guard and metal housing are copper alloy with nickel-tin plating.
The component is through-hole mounted and complies with RoHS and is lead-free. It is packaged in a box. The operating temperature range is -30°C to +120°C. The side interlocking feature allows multiple units to be joined together for multi-position assemblies.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.84 | $0.84 |
| 10+ | $0.76 | $0.76 |
| 50+ | $0.71 | $0.71 |
| 100+ | $0.66 | $0.66 |
| 500+ | $0.51 | $0.51 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This terminal block has 1 position.
The pitch is 10.00 mm (0.394 inches).
The UL current rating is 14 A, and the VDE current rating is 24 A.
The UL voltage rating is 300 VAC, and the VDE voltage rating is 750 VAC.
It is a through-hole mounting terminal block.
It accepts solid or stranded wire from 30-12 AWG (0.05-3.31 mm²).
The torque specification is 0.5 Nm (4 Lb·In).
