| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
15 pcs
|
15 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Current | |
| Current Rating | |
| Features | |
| Halogen Free | |
| Insulator Flammability Rating | |
| Insulator Material | |
| Lead Spacing | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| SVHC Present | |
| Screw Size | |
| Tape & Reel | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge | |
| Wire Termination |
The Würth Elektronik 691216610101 is a WR-TBL Series 2166 wire-to-board terminal block with a 10.16mm pitch and a single position. It is designed for horizontal entry with a screw rising cage clamp termination, accepting wire gauges from 12 to 30 AWG. The block is rated for 14A (UL) and 24A (VDE) current, with voltage ratings of 300V (UL) and 750V (VDE). Withstanding voltage is 1600V (UL) and 3000V (VDE).
The insulator is made of PA6/66 with UL94 V-0 flammability rating, and the contacts are copper alloy with nickel plating. The screw is steel with zinc plating. The terminal block features side interlocking for multiple units and is suitable for through-hole mounting. Operating temperature range is -30°C to +120°C. This product is packaged in a box and is RoHS3 compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.61 | $0.61 |
| 10+ | $0.52 | $0.52 |
| 50+ | $0.48 | $0.48 |
| 100+ | $0.42 | $0.42 |
| 500+ | $0.40 | $0.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
1 position.
10.16mm (0.400 inches).
14A under UL, 24A under VDE.
300V under UL, 750V under VDE.
Through hole mounting.
12 to 30 AWG.
-30°C to +120°C.
