The Würth Elektronik 690367290676 is a 6-position, 2-row rectangular receptacle connector designed for surface mount applications. It features a 2.54mm pitch and 1.50mm row spacing, making it suitable for board-to-board or cable connections. The connector uses stamped phosphor bronze contacts with a matt tin over nickel plating, rated for 1.5A per contact and 100VAC working voltage.
The housing is made of red PA6T with a UL94 V-0 flammability rating, ensuring reliable performance in demanding environments. The operating temperature range spans -40°C to 105°C. The connector includes a latch lock fastening mechanism and is designed for pick-and-place assembly. It is packaged in tape and reel for automated manufacturing.
Electrical characteristics include a contact resistance of 10 mOhm max, insulation resistance greater than 1000 MOhm, and a dielectric withstanding voltage of 500 VAC/min. The connector is certified for JEDEC lead free reflow soldering and is RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.95 | $0.95 |
| 10+ | $0.93 | $0.93 |
| 50+ | $0.90 | $0.90 |
| 100+ | $0.86 | $0.86 |
| 500+ | $0.77 | $0.77 |
| 800+ | $0.77 | $0.77 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54 mm per row.
It has 6 positions, all loaded, in 2 rows.
The current rating is 1.5 A per contact.
The working voltage is 100 VAC.
It is a surface mount connector with solder termination.
Yes, it is RoHS compliant and lead free.
The operating temperature range is -40°C to 105°C.
