| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
300 pcs
|
300 pcs | On Request | 1 | On Request | On Request | 17+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Amphenol ICC 68797-236HLF is a 36-position single row unshrouded header designed for board-to-board applications. It features a 2.54mm (0.100") pitch and male pin contacts made of phosphor bronze with a gold or GXT™ finish. The header is through hole mounted with solder termination, providing reliable electrical connections.
This header is rated for a current of 5A and a voltage of 110V, making it suitable for various low to moderate power interconnect needs. The black insulation is made of UL94 V-0 rated material, ensuring flame retardancy. The overall contact length is 0.413" (10.49mm) with a contact length of 2.54mm and insulation height of 2.54mm.
The unshrouded design allows for flexible mating with various connectors. It is typically used in electronic assemblies where a reliable, cost-effective board-to-board connection is required. The push-pull fastening type ensures simple insertion and extraction.
| Qty | Low | High |
|---|---|---|
| 1,200+ | $1.65 | $1.65 |
| 2,500+ | $1.62 | $1.62 |
| 5,000+ | $1.57 | $1.57 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
36 positions.
2.54mm (0.100").
5A.
110V.
Through hole with solder termination.
Gold or Gold, GXT™ with 15µin (0.38µm) thickness.
Single row.
