| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,257 pcs
|
1257 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,257 pcs
|
1257 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Cable End Type | |
| Connector | |
| Contact Finish | |
| Contact Material | |
| Current Rating | |
| FFC, FCB Thickness | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Locking Feature | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Tape & Reel | |
| Termination | |
| Voltage Rating | |
| Working Voltage |
The 68712414022 is a 24-position FPC connector from Würth Elektronik's WR-FPC series. It features a 0.5mm pitch and a top contact design with right angle surface mount termination. The connector incorporates a zero insertion force (ZIF) mechanism with a slide lock for secure cable retention.
Key specifications include a current rating of 1A and a working voltage of 125V (per datasheet). The contacts are made of phosphor bronze with tin plating, and the housing and actuator are constructed from liquid crystal polymer (LCP) with a UL94 V-0 flammability rating. The connector accepts FPC cables with a thickness of 0.30mm and a tapered end type.
Designed for compact electronic assemblies, this connector is suitable for applications requiring reliable, space-saving interconnections. It is packaged in tape and reel for automated assembly and is RoHS and lead-free compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.46 | $1.46 |
| 10+ | $1.41 | $1.41 |
| 50+ | $1.31 | $1.31 |
| 100+ | $1.21 | $1.21 |
| 500+ | $1.12 | $1.12 |
| 1,000+ | $1.02 | $1.02 |
| 2,000+ | $0.88 | $0.88 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 24 positions.
The pitch is 0.50mm.
The current rating is 1A.
The datasheet indicates a working voltage of 125V, while the input specification lists 50V. The datasheet value is considered more reliable.
It is surface mount, right angle.
The operating temperature range is -25°C to +85°C.
Yes, it is RoHS3 compliant and lead-free per the datasheet.
