| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
520 pcs
|
520 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The Amphenol ICC 68691-420 is a 20-position unshrouded male pin header with 2 rows of square pins on a 2.54mm pitch. Designed for through-hole soldering, it features phosphor bronze contacts with a 100µin tin finish for reliable low-resistance connections. The black insulation is rated UL94 V-0 for flammability resistance.
With an overall contact length of 13.67mm and a mating length of 3.05mm, this connector is suited for board-to-board stacking applications. The push-pull fastening system simplifies mating and unmating without locks. The 2.54mm row spacing matches standard pin strip grids.
This header is RoHS3 compliant and has an MSL rating of 1, indicating unlimited floor life. It is commonly used in a wide range of electronic assemblies requiring a cost-effective, reliable interconnect.
| Qty | Low | High |
|---|---|---|
| 900+ | $1.82 | $1.82 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100 inches).
20 positions, with all positions loaded, in 2 rows.
Through hole, with solder termination.
Phosphor bronze contact material with a tin finish, 100µin thick.
The part is marked as RoHS3 compliant (unverified from source data).
