| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The Amphenol ICC 68488-414HLF is a 14 position single row unshrouded male pin header designed for board-to-board applications. It features a 2.54mm (0.100") pitch and through hole right angle mounting with solder termination. The header uses square phosphor bronze contacts with a tin finish of 100.0µin (2.54µm) thickness. The insulation is black UL94 V-0 rated material with a height of 2.41mm (0.095"). The contact length is 5.84mm (0.230") and the fastening type is push-pull. This component is rated for 3A current and operates over a temperature range of -65°C to 125°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.85 | $0.85 |
| 10+ | $0.73 | $0.73 |
| 25+ | $0.67 | $0.67 |
| 100+ | $0.61 | $0.61 |
| 250+ | $0.55 | $0.55 |
| 1,000+ | $0.39 | $0.39 |
| 2,400+ | $0.33 | $0.33 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 14 positions, all loaded, in a single row.
The current rating is 3A.
Through hole, right angle mounting.
-65°C to 125°C.
Tin, 100.0µin (2.54µm) thickness.
