| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,200 pcs
|
1200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The 68001-416HLF is a through-hole header from Amphenol ICC designed for board-to-board applications. It features 16 male pin contacts arranged in a single row with a 2.54mm (0.100") pitch. The unshrouded design allows for easy mating and customization. Contacts are made of phosphor bronze with a tin finish of 100µin (2.54µm) thickness, providing reliable conductivity and solderability. The header is rated for 3A per contact and operates over a wide temperature range of -65°C to 125°C. The insulation material is rated UL94 V-0 for flammability. The overall contact length is 11.43mm (0.450"), with a contact length of 5.84mm (0.230") and insulation height of 2.54mm (0.100"). The square pin shape ensures secure mating with female receptacles. This header is suitable for prototyping, industrial control, consumer electronics, and telecommunications equipment where reliable point-to-point connections are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.87 | $0.87 |
| 10+ | $0.72 | $0.72 |
| 25+ | $0.70 | $0.70 |
| 100+ | $0.63 | $0.63 |
| 200+ | $0.61 | $0.61 |
| 600+ | $0.60 | $0.60 |
| 1,000+ | $0.59 | $0.59 |
| 5,000+ | $0.53 | $0.53 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
16 positions.
2.54mm (0.100").
3A per contact.
Through hole, solder termination.
-65°C to 125°C.
Tin, 100µin (2.54µm) thickness.
Unshrouded.
