| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
150 pcs
|
150 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The Amphenol ICC 68000-416HLF is a 16-position single row unshrouded header designed for board-to-board applications. It features male pin contacts with a 2.54mm (0.100") pitch and through hole solder termination for reliable PCB mounting.
The header has a push-pull fastening type and an insulation height of 2.54mm. Contacts are made of phosphor bronze with a tin finish (100.0µin thickness) and a square contact shape. The overall contact length is 0.425" (10.80mm) with a contact length of 5.84mm.
Rated for 3A per contact, the 68000-416HLF operates over a temperature range of -65°C to 125°C. The black insulator is rated UL94 V-0 for flammability. All 16 positions are loaded.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.69 | $0.69 |
| 10+ | $0.59 | $0.59 |
| 300+ | $0.46 | $0.46 |
| 600+ | $0.44 | $0.44 |
| 1,200+ | $0.42 | $0.42 |
| 5,100+ | $0.38 | $0.38 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 16 positions, all loaded.
3A per contact.
Through hole with solder termination.
