| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating | |
| Withstanding Voltage |
The Würth Elektronik 665303124022 is a WR-WTB series surface mount shrouded header designed for wire-to-board applications. It features 3 positions in a single row with a 1.00mm pitch, making it suitable for compact designs. The header is fully shrouded with a 4-wall design and uses a push-pull fastening mechanism for secure mating.
Electrical ratings include a current rating of 1A and a voltage rating of 50V AC. Contact resistance is 20mΩ maximum, insulation resistance is 100MΩ minimum, and the withstanding voltage is 500V AC. The operating temperature range is -25°C to 85°C.
Constructed with phosphor bronze contacts with tin finish and a liquid crystal polymer (LCP) insulator in beige color, the header meets UL94 V-0 flammability rating. It is packaged in tape and reel with a cap, compatible with automated pick-and-place assembly. Solder retention features aid in reliable soldering.
Compliance includes RoHS, REACH, and Halogen Free certifications. This component is ideal for general electronic equipment requiring a reliable, low-profile interconnect solution.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.94 | $0.94 |
| 50+ | $0.89 | $0.89 |
| 100+ | $0.83 | $0.83 |
| 250+ | $0.76 | $0.76 |
| 500+ | $0.64 | $0.64 |
| 1,000+ | $0.60 | $0.60 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
3 positions.
1.00mm (0.039 inches).
1A.
50V AC.
Surface Mount.
-25°C to 85°C.
